E 212 230 V * Electric linear drive for automation of fanlight openers
- Cost-effective and simple motorised solution for activating several scissors
- Can be integrated perfectly into the façade design thanks to its slim and discreet look
- Opening width variably adjustable over stroke length and can be adjusted as necessary
- Load cut-off and integrated limit switch as well as stroke are adjustable
- Completely pre-mounted assembly groups facilitate installation
Application Areas
- Automation of GEZE OL 90 N, OL 95 N and OL 320 fanlight openers
- Natural ventilation in the façade area
- Inward-opening bottom-hung leaves
- Installation on wooden, PVC or metal windows
- Frame installation
Technical data
E 212 230 V | |
Dimensions | 210 x 80 x 33 mm |
Space needed on frame (min.) | Necessary space should be determined individually |
Space requirement on leaf (min.) | Necessary space should be determined individually |
Compressive force | 1500 N |
Tensile force | 1500 N |
Operating voltage | 230 V AC |
Current consumption | 0.2 A |
Power consumption | 50 W |
Duty rating | 25 % |
Min. core cross section | 1.5 mm² |
Service temperature | -20 - 60 °C |
IP rating | IP42 |
Type of stroke shortening | Mechanical |
End position cut-off extended | Limit switches |
End position cut-off retracted | Limit switches |
Overload cut-off | Yes |
Bottom-hung window INWARD-opening frame installation | Yes |
