Boxer ISM-EFS
Closer body Boxer EFS 4-6 * Main body for integrated door closer size EN 4-6 with electric free swing function incl. free swing lever with comfort hold-open function
- All functions can be adjusted in the installed state
- Closing speed can be adjusted from the top via valves
- Latching action can be adjusted from the top via valve
- Electric free swing function
- Mechanical, adjustable back check in the guide rail
- Door closer, can be used for right and left hand doors
- Spindle extensions up to 8 mm available
- Supply voltage 24 V DC
- Minimal installation effort due to low number of individual parts and quick setting
Application Areas
- Fire and smoke protection doors, proof of suitability for the door required
- Right and left single-action doors
- Single-action doors up to 1400 mm leaf width and 180 kg leaf weight
- Integrated installation
- Hold-open systems with integrated hold-open function with free swing
- Barrier-free access in accordance with DIN 18040
Technical data
| Closer body Boxer EFS 4-6 | |
| Closing force in accordance with EN 1154 | EN 4 - 6 |
| Leaf width (max.) | 1400 mm |
| Leaf weight (max.) | 180 kg |
| Opening angle (max.) | 120 ° |
| Identical design for DIN left and DIN right | Yes |
| Input voltage | 24 V DC |
| Electrical power consumption | 2 W |
| Duty rating | 100 % |
| Residual ripple | 20 % |
| IP rating | IP43 |
| Standard conformity | EN 1154:1996/A1:2002/AC:2006, EN 1155 |
| Suitability for fire protection doors | Yes |
| Length | 332 mm |
| Width | 40 mm |
| Height | 54 mm |
| Closing force adjustable | Yes, stepless |
| Adjustable closing speed | Yes |
| Latching action adjustable | Yes, via valve |
| Back check integrated | Mechanically in the guide rail |
| Position of closing force adjustment | Top |
| Safety valve againts overload | Yes |
| Hold-open function | Electrically, for free swing function |
