Link arm 1-leaf
TS 1000 C * Overhead door closer with link arm for 1-leaf doors with a leaf width of up to 950 mm
- Variable closing force of EN2 or EN3 by turning the bearing block around
- Can be used for right and left hand doors without conversion
- Hydraulic latching action which accelerates the door shortly before it is closed
- Closing speed can be individually adjusted
Application Areas
- Right and left single-action doors for interior use
- Single-action doors up to 950 mm leaf width
- Door leaf installation hinge side and transom installation opposite hinge side
- Door leaf installation opposite hinge side in parallel arm installation possible
Technical data
| TS 1000 C | |
| Closing force in accordance with EN 1154 | EN 2/3 |
| Leaf width (max.) | 950 mm |
| Type of installation | Door leaf installation hinge side, Transom installation opposite hinge side, Door leaf installation opposite hinge side |
| Opening angle (max.) | 180 ° |
| Identical design for DIN left and DIN right | Yes |
| Standard conformity | EN 1154:1996/A1:2002/AC:2006 |
| Suitability for fire protection doors | Yes |
| Length | 215 mm |
| Width | 44 mm |
| Height | 52 mm |
| Closing force adjustable | Yes, via installation |
| Adjustable closing speed | Yes |
| Latching action adjustable | Yes, via link arm |
| Back check integrated | No |
| Position of closing force adjustment | Mounting position |
