Door draw-in damper
GEZE ActiveStop surface-mounted configured Door damping on both sides for interior swing doors, configured for timber or glass doors
- Door opening angle with variable adjustment from 80°-140°
- Can be used for right and left hand doors without conversion
- Soft opening and closing of doors up to max. 45 kg leaf weight
- Gentle stopping, quiet closing and comfortable keeping open of doors
- Practically eliminates slamming doors, trapped fingers, and damage to walls and furniture
- Secure holding of the door when open, meaning no door is stopper necessary
- Opening and latching speed when installed can be set via a valve
- Integrated safety valve offers overload protection
Door damping on both sides for interior swing doors, configured for timber or glass doors
Application Areas
- Right and left single-action doors for interior use
- Room doors with high access convenience
- Single-action doors up to 1100 mm leaf width
- Surface-mounted installation, for retrofitting on existing doors
- Barrier-free access in accordance with DIN 18040-2
Installation situations in reference objects and videos
The new door control GEZE ActiveStop - door damper Product video
The GEZE ActiveStop door damper can gently stop doors, close them quietly and hold them open comfortably. This eliminates annoying banging doors and damaged walls and furniture.
GEZE ActiveStop, surface mounted, glass door
Draw-in damper on both sides for single-action doors without fire protection demands © GEZE GmbH
Technical data
| GEZE ActiveStop surface-mounted configured | |
| Depth | 34 mm |
| Height | 68 mm |
| Leaf weight (max.) | 45 kg |
| Leaf width (max.) | 1100 mm |
| Category of door | flush-mounted, rebated |
| Identical design for DIN left and DIN right | Yes |
| Installation type | surface-mounted |
| Adjustable draw-in damper | Yes, via valve |
| Draw-in damper in direction of closing movement from | 25 ° |
| Free swing area | 25 ° - 60 ° |
| Draw-in damper in direction of opening movement from | 60 ° |
| Adjustable door opening angle | Yes, stepless |
| Hold-open position adjustable | 80 ° - 140 ° |
| Safety valve againts overload | Yes |
